标准

IEEE 802.3 10Base-T

IEEE 802.3u 100Base-Tx

交换特性

MAC Table:  1K

Packet Buffer: 448K

Packet Forwarding Rate: 0.744Mpps

Switching Delay: <5us

通信接口

Electrical Ports:  5 10/100Base-Tx (RJ45)

前面板指示灯

Power LED:  PWR

Interface LED: RJ45(Link&ACT) ,

电源

Power Terminal:   5-pin 3.81mm-spacing plug-in terminal block

Full load power consumption:

5port RJ45 <1W

Overload Protection: Support

Reverse Connection Protection: Support Redundancy Protection: Support

物理特性

Housing: Metal, fanless

Protection Class: IP40

Dimensions : 30mm x 115mm x 90mm (W×H×D)

Weight:  0.45kg

Mounting: DIN-Rail or Panel mounting
